| Case Specification |
|---|
| Dimensions | 463 x 220 x 486 mm (DWH) | | Form Factor | Mid Tower | | Materials | Steel + Plastic | | Mainboard Support | ATX, M-ATX, ITX | | Front Access & Controls | Power, LED Control Button, 2 x USB3.0, HD-AUDIO | | Side Panel | 4 mm Tempered Glass Side Panel |
|
| Expansion & Drive Bays |
|---|
| Expansion Slots | 7 | | 5.25" | 1 | | 3.5" /2.5" | 3/2 | | 2.5" | 3 |
|
| Fan |
|---|
| Front | 3 x 120mm/2 x 140mm | | Top | 3 x 120mm / 2 x 140mm (w/o ODD and w/o ODD bracket)
2 x 120mm / 2 x 140mm (w/o ODD but with ODD bracket)
2 x 120mm / 1 x 140mm(When ODD is installed) | | Power Supply Shroud | 2 x 120mm | | Rear | 1 x 120mm | | Pre-installed Fans | 3 x 120mm ARGB fans in front
1 x 120mm fan (Reverse Fan) on PSU shroud
& 1 x 120mm fan in rear |
|
| Radiator Support |
|---|
| Front | 120/240/280/360mm (≤ 55mm thickness when fans are installed outside of front panel)
(≤ 30mm thickness when fans are installed inside of front panel)
[Max Radiator Length ≤ 405mm] | | Top | 240/280/360mm (w/o ODD and w/o ODD bracket)
240/280mm (w/o ODD but with ODD bracket)
120mm(When ODD is installed)
[Max Radiator Length ≤ 405mm] | | Rear | 120mm |
|
| Clearance |
|---|
| Max GPU Length | ≤ 405mm | | Max CPU Cooler Height | ≤ 175mm | | Max PSU Length | ≤ 205mm |
|
| Miscellaneous |
|---|
| Dust Filter | Front / Top / Bottom / Right Hand Side | | Net Weight | 7.55KG | | Gross Weight | 8.7KG | | Warranty | 2 years | | UPC# | 0-761345-80050-1 |
|
