Stock Status: In Stock

Manufacturer: GIGABYTE

  • Form Factor: PCl Express Card
  • Interface: PCI-Express 3.0 x4, NVMe 1.3
  • Total Capacity: 1TB*
  • Sequential Read Speed : up to 3480 MB/s**
  • Sequential Write speed : up to 3080 MB/s**
  • TRIM & S.M.A.R.T supported
  • AES 256-bit Hardware Encryption Self-Encrypting Drive (SED)
  • Warranty: Limited 5-years

  • Interface
    PCI-Express 3.0 x4, NVMe 1.3
  • Form Factor
    PCl Express Card
  • Total Capacity
  • NAND
    3D TLC ToshiBa BiCS3
  • External DDR Cache
  • Sequential Read speed
    Up to 3480 MB/s
  • Sequential Write speed
    Up to 3080 MB/s
  • Random Read IOPS
    Up to 610K
  • Random Write IOPS
    Up to 530K
  • Mean time between failure (MTBF)
    1.8 million hours
  • Power Consumption (Active)
    Average : R : 6.2W : 5.9W
  • Power Consumption (Idle)
  • Temperature (Operating)
    0°C to 70°C
  • Temperature (Storage)
    -40°C to 85°C
  • Warranty
    Limited 5-years or 1600TBW
  • Note
    * Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
    * Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark v.5.1.2 and I0meter 1.1.0.
    * Speeds based on internal testing. Actual performance may vary.
    * TBW (Terabyte Written):Terabytes Written" is the total amount of data that can be written into an SSD before it is likely to fail.
    * 1GB = 1 billion bytes. Actual useable capacity may vary.
    * 5 years or 1600 TBW, whichever comes first.
    * TBW is evaluated by JEDEC workload standard.
