| Case Specification |
|---|
| Dimensions | 467 x 220 x 486 mm(DxWxH) | | Form Factor | Mid tower | | Materials | Steel + Plastic | | Mainboard Support | ATX , Micro-ATX, Mini-ITX | | Front Access & Controls | Power, LED Control Button, 2 x USB3.0, HD-AUDIO | | Side Panel | 4 mm Tempered Glass Side Panel |
|
| Expansion & Drive Bays |
|---|
| Expansion Slots | 7 | | 5.25" | － | | 3.5"/2.5" (convertible) | 3/2 | | 2.5" | 3 |
|
| Fan |
|---|
| Front | 3 x 120mm / 3 x 140mm | | Top | 3 x 120mm / 2 x 140mm | | Power Supply Shroud | 2 x 120mm | | Rear | 1 x 120mm | | Included Fan(s) | 3 x 120mm ARGB fans in front
1 x 120mm fan (Reverse Fan) on PSU shroud
& 1 x 120mm fan in rear |
|
| Radiator Support |
|---|
| Front | 120/240/280/360mm (≤ 55mm thickness when fans are installed outside of front panel)
(≤ 30mm thickness when fans are installed inside of front panel) | | Top | 120/240/280/360mm | | Rear | 120mm |
|
| Clearance |
|---|
| Max GPU Length | ≤ 405mm | | Max CPU Height | ≤ 175mm | | PSU Support | ≤ 205mm |
|
